Videojet® 3340 CO₂ Laser Marking System

The 3340 30-Watt laser marking system offers a powerful combination of performance and flexibility, delivering high quality marks on moderate to high speed lines. Designed to maintain the best quality codes on high speed lines. Virtually no font, code or graphic restrictions, makes the 3340 an ideal solution for marking complex codes to meet the demand of applications in food, beverage, cosmetics, pharmaceutical and extrusion industries. A diverse combination of marking heads, lenses and wavelength options delivers an industry leading 21 spot size variations to match a broad range of marking effects.

Specs
Benefits
Applications
Documents

Specification	Value
Laser Tube	CO₂
Maximum Power	30W
Laser Cooling	Air Cooled
Maximum Print Speed	2000 characters/sec
Maximum Line Speed	900 m/min (2,940 ft/min)
Environmental Protection	IP54, 65
Beam Output	Steered Beam
Laser Source Expected Life	45,000 hours
Laser Wavelength Options	10.6 μm, 10.2 μm, 9.3 μm
Focal Distance Options	64 mm (2.50 in) – 600 mm (23.62 in)
Maximum Mark Window	601 x 440 mm (23.66 x 17.32 in)
Standard I/O Connectivity	Internal Terminal Connections
Standard User Interface	Handheld
Optional User Inteface	PC, CLARiTY™ Laser Controller, TCS, Smart Graph Com
Umbilical	Detachable , 3 lengths
Plant Air Used	No
Certifications/Approvals	CE, TÜV/NRTL, FCC Compliance (no certification required): ROHS, CDRH/FDA

Uptime Advantage helps keep productivity up and costs down:

Laser tube designed with larger gas volume has optimized air-cooling to provide operational life of over 45,000 hours
Optional IP65 makes printer suitable for harsh environments without need for plant air
CLARiTY™ Laser Controller reduces operator errors, helping to ensure products are coded correctly and advanced productivity tools identify the root cause of downtime events to make sustainable process improvements.

Engineered for high performance and quality:

Highly focused laser beams achieve better performance (mark contrast) than other laser solutions without needing higher power
Three available laser wavelengths, four marking heads and thirteen lenses for optimal code quality on your specific materials
High speed communication and buffering of variable data content delivers improved character formation, over other laser solutions, for customers who don’t need top speed, allowing more time to engage the product, resulting in crisp, legible codes

Flexibility and simple usability comes as standard:

Largest marking field in the industry (up to 600mm width) offers optimally matched applications for faster marking, increasing discrete product throughput or marking multiple messages across a wide web application using only one laser
32 standard beam delivery options for integrating the laser marking system into your packaging or filling equipment can help produce the best system uptime
Focus finder tool for quick set up of accurate focal distance and detachable umbilical for easy integration and line changeover
